From vision to production
Mechanical engineers spend over 25% of their time creating 2D drawings manually. REV1 turns your 3D CAD models into fully annotated, production-ready drawings in minutes.
Recover
25%
of engineering time
Apply automatically
GD&T based on 300+ pages of ASME rules
Review and edit
Review
12
before it hits the shop floor
Sync
Stays synced with your PLM
Communicate your design intent in 3D
Start with your 3D model and tell REV1 what matters — which surfaces are critical, what type of fit is required. Imagine explaining the part to your coworker while spinning the CAD.
Drawing generation in minutes instead of hours
REV1 generates a fully annotated 2D drawing — selecting the right geometric controls and tolerance values based on your part's function.
